Ebike Electric Motorcycle 48V/60V/72V 60A 3Mode Waterproof Brushless Controller Lcd

SKU: 1000

Type: SM7260                          Voltage: 48V,60V,72V

Max Dc Current: 60A                Drive mode: 3 Mode

LCD meter: 2 protocol              Function: Throttle ,brake ,pas ,light control,self-study

Size: 220*105*58mm                Weight: 1.1kg

Application: Electric Bike ,Electric Motorcycle

0.0 (0 Reviews)
0 Sold
$50.00 $45.00
Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity
-
+
  • Ebike Electric Motorcycle 48V/60V/72V 60A 3Mode Waterproof Brushless Controller Lcd
  • Ebike Electric Motorcycle 48V/60V/72V 60A 3Mode Waterproof Brushless Controller Lcd
  • Ebike Electric Motorcycle 48V/60V/72V 60A 3Mode Waterproof Brushless Controller Lcd
  • Description

Type

SM7260

Voltage

48V,60V,72V

Max dc current

60A

Drive mode

3 mode

LCD meter

2 protocol

Size

220*105*58mm

Weight

1.1kg

Application

Electric bike ,electric motorcycle

Function

Throttle ,brake ,pas ,light control,self-study

How to use self-study function?

After the controller and the motor are connected for the first time, the motor should be supported without any load, power on the controller, insert the learning line, observe the rotation direction of the motor, if it is the forward direction, remove the learning line, and end the learning; If the direction is reversed, remove the learning line and then insert the learning line, the motor rotation direction changes, at this time remove the learning line, you can run normally.
